Production line for sharpening carbide-tipped band saw blades for highly precise complete machining
Carbide-tipped band saw blades are finding more and more uses in the metal-cutting industry. The highest standards are placed on the accuracy of tooth geometries. As a market leader in sharpening machines for carbide-tipped saw blades, VOLLMER has now developed a new range of machines for precise sharpening of these band saw blades with a blade width of up to 150 mm. It consists of the following machine types:
- CB 400 CNC-controlled automated sharpening machine for tooth top and straight tooth face grinding
- CBF 400 CNC-controlled automated sharpening machine for tooth flank grinding on both sides
The machining tools are usually linked together to form a line and the strip stock to be machined is fed from the coil and finish-machined.
YOUR MAIN ADVANTAGES AT A GLANCE
- Particularly stable machine construction, essential for maximum precision
- All functions are CNC-controlled
- Vollmer PMC multiprocessor control
- Greater flexibility due to the integrated measuring sensor
- Simple operator prompts on the LCD colour display, supported with graphics
- CB 400 with the option of automated machining of the hollow face or chip breaker
- Bevel grinding option
- Excellent sharpening results using grinding oil as coolant
CB 400: Specifications
| CB400 | |
|---|---|
| WERKSTÜCKDATEN | |
| BANDSÄGEBLÄTTER | |
| Bandsägeblätter mit Blattbreite | 12 - 150 mm |
| Bandsägeblätter mit Stammblattdicke | 0,5 - 2,0 mm |
| ZAHNGEOMETRIE | |
| Spanwinkel | -25° - +25° |
| Achswinkel | ≤ 30° |
| Freiwinkel | 0° - +25° |
| Schrägungswinkel | ≤ 60° |
| Zahnteilung | 4,2 - 200 mm |
| WERKZEUGDATEN | |
| GESCHWINDIGKEITEN | |
| Schleifgeschwindigkeit | 0.1 - 20 mm/s |
| SCHNITTSTELLEN | |
| Anschlusswert elektrisch | 5,0 kVA |
